EPS Machine MAXI-2040
Styrofoam Machining Center/ Foam Cutting Machine
Standard Configuration:
1) HSD 6.0 KW water- cooling spindle
2) Syntec control system made in Taiwan
3) Yaskawa Servo system made in Japan
4) ELSELE reducer made in Germany
5) THK Linear guide
6) DELTA Inverter made
7) German Schneider Electronic Spare Parts
8) Japanese OMRON Switch
9) Dust cover for X and Y Axis
10) Guard plate for all the four sides.
11) There is adjustable point of support in the middle of the bed
Application:
1) Mould Industry: Engraving and Cutting large nonmetal mould. Especially for Auto Foam Mold, Aviation Wood Mold, Ship Wood Mold, Train Wood Mold and so on
2) Instrument Industry: Shaping large instrument and Engraving on the three-dimensional surface.
Suitable material:
Wood, Styrofoam (EPS) and non-metallic carbonation materials
Technical Parameters:
No.
|
Item
|
|
Parameters
|
1
|
Working area
|
X
|
2000mm (Option: 2000 mm)
|
Y
|
4000mm (Option: 5000 mm)
|
Z
|
1000mm
|
2
|
Table
|
Size
|
2000 x 4000mm
|
Material
|
HT250
|
3
|
Structure
|
Table Structure
|
Whole Cast Steel
|
Transmission way of X/Y/Z
|
X/Y with gear rack
Z with ball screw
|
4
|
Speed
|
Feed
|
1-10000mm/min
|
Rapid feed rates
|
X=12000mm/min
|
Y=12000mm/min
|
Z=10000mm/min
|
5
|
Spindle
|
Spindle Power
|
6.0KW
|
Spindle Speed
|
100-10000 RPM /min
|
Spindle taper
|
BT 40
|
Distance from Nose to Table Top
|
150-1150mm
|
6
|
Driver
|
|
Yaskawa Servo motor
|
7
|
Working Voltage
|
|
AC380V/50Hz
|
8
|
Commend Code
|
|
G Code/ F/S Code Compatible
|
9
|
Operating System
|
|
Syntec (Option: OSAI controller)
|
10
|
Net Weight
|
|
8000 KGS
|
