Standard Configuration:

1)         Working area: 1300mm*2500mm*200mm

2)         9.0 kw HSD spindle

3)         Vacuum table (Germany Becker vacuum pump)

4)         SYNTEC controller system

5)         Panasonic Servo drivers and motors

6)         DELTA inverter made in Taiwan

7)         Linear 6 position tools magazine

8)         Original Type 3 software

9)         German Schneider Electronic Spare Parts

10)     Japanese OMRON Switch

11)     THK Linear guide made in Taiwan

12)     3PH 380V 50Z

13)     Plywood case package

Option items:

1)       Oil mist cooling system

2)       Dust collect system

3.0   KW single bag

5.5 KW single bag

3)       Extra tool holders

4)       Working area:  1500*3000*200 mm

                 2000*3000*200 mm

                 2000*4000*200 mm

5)       Z axis up to 300~400 mm

Applications:

1)       Woodworking: wood panel, three-dimensional wave board processing, handicraft fan window processing. Cutting, engraving, routing, drilling on cabinet doors, solid wood door, complex wood door, Paint-free door.

2)       Other Industry: make building models, wood mold, air wooden mold, propeller, automotive foam mold. Shaping three-dimensional surfaces such as violin, erhu musical instruments and so on

3)       Pattern carving, calligraphy tablet design and frame sculpture.

Technical parameters:
